Material out of tank
Stainless Steel.
Material of inner tank
Food grade stainless steel 304-2B with Protective TIG welding.
Tank insulating layer
PUF Insulation 50/55/60 mm thickness with high density.
Welding:
Argon arc welding
Tube structure
All-glass double deck co-axial structure
Glass material
High borosilicate 3.3 glass
Outer tube diameter and glass thickness
∅58±0.7mm; Glass thickness 1.6±0.15mm
Inner tube diameter and glass thickness
∅47±0.7mm; Glass thickness 1.6±0.15mm
Bracket:
Stainless steel structure
Bracket angle:
22, 38, 45 optional, pitched roof, flat roof optional
Fastening pieces:
Stainless Steel Nut Bolt
